SY-41 Synergi Electric - online training (subscription)

This is a training subscription service that delivers a weekly live webcast on standard Synergi Electric training topics, in addition to some more advanced topics up to twice a month.

Description

Synergi Electric Online Training is a training subscription service that delivers a weekly live webcast on Synergi Electric training topics. A dedicated Q&A session is also offered each month to address any technical issues or application questions.

The subscription service provides unlimited access to this content, both live online and recorded sessions, while the subscription is active. Topics and schedules will be published in advance and new material will cycle every 14-16 weeks. Please register your interest above or contact your sales manager to get more information on this new and exciting offering from DNV.

Learning objectives

Unlike a standard classroom course, our online subscription service is a continuous learning model that offers more time to retain the content between the classes which allows the users to get additional hands on time with the software and retain more of the material. It also allows the users to pick and chose the topics that are most relevant for them.

Target group

Utilities and consultancies with new or infrequent users who need a refresher course, or engineers looking for more information on the latest Synergi Electric functionality.

Class title Class description Class title Class description

Class title

Class 1: User interface & model management

Class description

  • Synergi user interface
  • Help, User Guide, Technical Reference
  • Saving & loading models
  • Using DBMS & tools
  • Selecting feeders
  • Looking at the database

Class title

Class 2: Analysis, results & reports

Class description

  • Running analysis
  • Reports & features
  • Results tabs
  • Results sets, view modes, explorer
  • Charts & viewers
  • EA Automation

Class title

Class 3: Model building

Class description

  • Adding, deleting, connecting
  • Adding & removing taps
  • Adding, moving, copying equipment
  • Multiple editor
  • Data Lake, MiddleLink, subsets, Forge
  • Node reduction

Class title

Class 4: Modelling & time of day

Class description

  • Line construction report
  • Feeders, sources, network definition
  • Facility models
  • Loads
  • Time-of-day settings
  • Load profiles

Class title

Class 5: Load-flow applications

Class description

  • Load-flow algorithm
  • Important settings
  • Single-hour & 24-hour analysis
  • 576 & 8760 analysis
  • Multi-year analysis
  • Scaling & growth tools

Class title

Class 6: Load allocation & forecasting

Class description

  • Allocation factors
  • Meters & demands
  • Feeders, subs, reclosers
  • Allocation settings & options
  • Secondary allocation
  • Forecasting

Class title

Class 7: PV & DER Analysis

Class description

  • Settings, displays & views
  • Gens, large customers, rooftop
  • Inverters
  • Hosting capacity applications
  • Screening
  • PV applications

Class title

Class 8: Fault & Arc Flash

Class description

  • Source modelling
  • Impedance calcs and viewing
  • Fault, fault flow, fault voltage
  • Fault location
  • Arc Flash 2002/2012
  • Arc Flash 2018

Class title

Class 9: Protection & TCCs

Class description

  • Protection database
  • Generating a TCC
  • TCC options
  • Check coordination
  • Protection lab (light table)
  • Supporting tools

Class title

Class 10: Switching & capacity planning

Class description

  • Network definition
  • Contingency & switch plan manager
  • Throw-over analysis
  • AFS analysis
  • Switch plans
  • Phase balancing & capacitor placement

Class title

Class 11: Reliability, Power Quality

Class description

  • Failure rates & exposure zones
  • Using actual events
  • Reliability settings & results
  • Harmonic impedance scan
  • Harmonic load-flow
  • Duct bank modelling

Class title

Class 12: Batch, scripts, macros

Class description

  • Batch analysis
  • Time-series analysis
  • Recipes (macros)
  • Clean-up scripts
  • SQL Dashboard
  • Solver / Python

Class title

Class 13: Secondary modelling

Class description

  • Explicit secondary modelling
  • Implicit modelling
  • Data on the sections
  • Primary / secondary switch
  • Secondary results
  • Losses

Class title

Class 14: Growth, ADMS, scaling

Class description

  • Scale manager
  • Setting up and using growth options
  • ADMS
  • Weather & time
  • Uncertainly analysis

Class title

Class 15: VVO & performance evaluation

Class description

  • Capacitor settings
  • VV evaluation and screening
  • Model inspector
  • System health
  • Regression
  • Capacitor flicker

Class title

Class 16: Network & transmission

Class description

  • Network modelling
  • Network N-3 contingency
  • Transmission modelling
  • Types of load-flow
