Phast™ CFD Add-Ons
Modelling the impact of 3D surroundings
Three CFD add-ons powered by KFX software are currently available: Phast CFD pool fire, Phast CFD jet fire and Phast CFD dispersion.
The CFD fire add-ons provide results in the form of flame shapes, and temperature and radiation isosurfaces and isocontours in a rich, three-dimensional viewer. Conversely, the CFD dispersion add-on provides results in the form of temperature and concentrations isosurfaces and isocontours for unignited flammable releases.
Phast CFD - jet fires add-on
This add-on supports detailed modelling of standalone jet fire scenarios based on jet source terms which can be calculated from pressure, temperature and hole size.
Our customers use this for designing fire walls, determining radiation from a flare, layout design and much more.
Answer |
---|
AnswerThe CFD calculations in Phast are powered by KFX, which means that the same scenario in Phast CFD and KFX will produce the same results. KFX, however, has some advanced features not available in Phast CFD.
|
Answer |
---|
AnswerYou can create custom 3D objects (cuboid, cylinders) directly in Phast. Alternatively, there are third party solutions for creating your own 3D models. |
Answer |
---|
AnswerYes, they are as they are separate and independent extensions. You can purchase / lease one or both. |
