DNV GL introduces next generation energy efficiency methodology
DNV GL presents a novel approach that overcomes challenges of assessing on board energy efficiency in a consistent manner. As a result, priorities for improvement can be determined accurately. In a new report released today, DNV GL answers the question: How can a ship manager identify the biggest sources of useful energy that are currently being wasted on their ships?
Illustration
“Ship operations and environmental legislation have become more complex, and it has become increasingly difficult to assess or even define efficiency with consistency and accuracy,” said Rune Torhaug, Director, Strategic Research & Innovation, DNV GL. “We have therefore revisited the basic and universal laws of thermodynamics to develop a methodology based on exergy, sometimes called available energy, which is a metric for describing the maximum useful energy that can be derived from a process, component or system.”
The methodology can be adjusted to suit newbuilds still in the design phase or operating ships, and it is designed to help managers make the most out of their Ship Energy Efficiency Management Plans. Using both on board measurements and the DNV GL modelling suite COSSMOS, energy losses throughout the ship including hull, propulsion power train, machinery and electrical systems are quantified and ranked. Even difficult-to-capture processes such as throttling and fluid mixing can be incorporated.
The report includes an analysis of a waste heat recovery system. These complex systems can easily contain 70 components. “Through our exergy-based methodology, the true sources of useful energy losses were identified, revealing a picture far from self-evident. Subsequent optimisation in DNV COSSMOS yielded an increase in fuel savings that halved the payback time of the system,” said George Dimopoulos, senior researcher and project manager of this position paper.
A second study examined the fuel pre-processing sub-system for the marine fuel cell on board the offshore supply vessel Viking Lady. This resulted in a solution capable of a remarkable 50 per cent reduction in exergy losses.
When the main engine of an aframax tanker was analysed using operating data in combination with COSSMOS modelling, the true sources of losses were identified with greater accuracy than a traditional energy analysis, says Dimopoulos. “In fact, the standard energy analysis failed to identify the turbocharger as being the second largest contributor to exergy loss.”
With this ‘common currency’ for efficiency, DNV GL provides a way of energy management that will work for all ships, and all system and components that convert energy on board. It thus offers ship managers an unparalleled way of prioritising investment in technology alternatives or new operational strategies.
About DNV GL
Driven by its purpose of safeguarding life, property and the environment, DNV GL enables organisations to advance the safety and sustainability of their business. We provide classification and technical assurance services along with software and independent expert advisory services to the maritime, oil & gas and energy industries. We also provide certification services to customers across a wide range of industries. Operating in more than 100 countries, our 16,000 professionals are dedicated to helping our customers make the world safer, smarter and greener.
About DNV COSSMOS
Developed by DNV GL Strategic Research & Innovation DNV COSSMOS is a computer platform that models, simulates and optimises complex and integrated ship machinery systems with respect to energy efficiency, emissions, costs and safety. With COSSMOS DNV GL is able to analyse alternative configurations in new vessels, perform assessment and optimisation in ships in operation systems, and evaluate the potential of new technologies.
